    · HOME >Product>Textile>Endless felt for Compacting Machine


    * Machine : Ferraro,Sperotto Rimar, Santex, Lafer Heliot, Monti, Monforts, Mersan, Serteks, Bianco, Weiss, Stram, fong’s,
      I Kuwang, Ssang Ho, Sun Keung, Poong Kwang etc.

    Material Nomex (Meta Aramid), Polyester, Wool
    Working Temperature

    Nomex 100%                                     : 230℃ - Heat Compacting m/c
    Nomex 50% (Surface) + Polyester 50% : 180℃ - Heat Compacting m/c
    Nomex 30% (Surface) + Polyester 70% : 150℃ - Steam Compacting m/c
    Polyester 100%                                 : 150℃ - Steam Compacting m/c
    Property < 1% Elongation at 30kg/cm (20mm Thick)
    Dimension

    Width                      : < 3,200mm
    Inner Circumference : 2,000~6,000mm
    Thickness               : 18 ~ 22mm
    Weight                    : 8,000g/m2 (20mm Thick)
    ※ Other material and dimension available on customer’s request.
